• Drilling Capacity: 25 mm (1”)
• Spindle Speed: 8 different speed settings
• Speed Range: 90 to 2800 RPM
• Spindle Nose: MT-3 (Morse Taper 3)
• Spindle Centre to Column Distance: 200 mm (8”)
• Spindle Travel: 150 mm (6”)
• Maximum Distance Spindle to Table: 650 mm
• Maximum Distance Spindle to Base: 940 mm
• Working Surface of Base: 290 mm x 290 mm
• Working Surface of Table: 300 mm (12”) Round
• Column Diameter: 58 mm
• Machine Base Dimensions: 470 mm x 290 mm
• Motor: 1 HP, 1440 RPM
• V-Belt Size: A-42
• Weight: Approx. 80 kg
• Model Type: Light Duty (Eco), with an M.S. Iron Gear Set

25 MM (1”) Pillar Drilling Machine

Model: RTD-15 L

• Drilling Capacity: 25 mm (1”)
• Spindle Speed: Eight speeds
• Speed Range: 90 to 2800 RPM
• Spindle Nose: MT-3
• Spindle Centre to Column: 200 mm (8”)
• Spindle Travel: 150 mm (6”)
• Maximum Distance (Spindle to Table): 650 mm
• Maximum Distance (Spindle to Base): 940 mm
• Working Surface (Base): 290 x 290 mm
• Working Surface (Table): 300 mm (Round) (12”)
• Column Diameter: 58 mm
• Machine Base: 470 x 290 mm
• Motor: 1 HP / 1440 RPM
• V-Belt Size: A-42
• Weight: Approximately 80 kg

Special Feature: Eco Light Duty (Square), with M.S. Iron Gear Set

• Drilling Capacity: 25 mm
• Spindle Speed: 8-speed options
• Speed Range: 87 to 3600 RPM
• Spindle Nose: MT-3 (Morse Taper #3)
• Spindle Centre to Column Distance: 200 mm
• Spindle Travel (Stroke): 150 mm
• Max Distance (Spindle to Table): 650 mm
• Max Distance (Spindle to Base): 940 mm

• Working Surface of Base: 320 x 320 mm
• Working Surface of Table: 310 mm (Round)
• Column Diameter: 74 mm
• Machine Base: 470 x 320 mm

• Motor: 1.5 HP, 1440 RPM
• V-Belt Size: A-44

• Machine Weight: Approx. 110 kg
• Machine Type: Light Duty, Round Base (Geared)

The RTD-17 Pillar Drilling Machine is a versatile and robust machine ideal for various industrial applications. Here's a summary of its key specifications:

• Drilling Capacity: 25 mm
• Spindle Speed: Eight-speed settings
• Speed Range: 87 to 3600 RPM
• Spindle Nose: MT-3 (Morse Taper #3)
• Spindle Centre to Column Distance: 250 mm
• Spindle Travel: 150 mm
• Maximum Distance (Spindle to Table): 930 mm
• Maximum Distance (Spindle to Base): 1200 mm
• Base Working Surface: 360 x 400 mm
• Table Working Surface: 395 mm (Round)
• Column Diameter: 74 mm
• Base Dimensions: 550 x 380 mm
• Motor Power: 1.5 HP at 1440 RPM
• V-Belt Size: B-52
• Machine Weight: Approximately 155 kg
• Model Variants: Regular duty (round) and fine feed model (geared)

specifications for a pillar drilling machine model RTD-17. Here’s a summary of its key features:

• Drilling Capacity: 25 mm (1 inch)
• Spindle Speed: Eight speeds ranging from 87 to 3600 RPM
• Spindle Nose: MT-3 (Morse Taper 3)
• Spindle Centre to Column: 250 mm
• Spindle Travel: 150 mm
• Maximum Distance Spindle to Table: 930 mm
• Maximum Distance Spindle to Base: 1200 mm
• Working Surface of Base: 360 x 400 mm
• Working Surface of Table: 395 mm round
• Column Diameter: 74 mm
• Machine Base: 550 x 380 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-52
• Weight: Approximately 155 kg
• Model Type: Regular Duty, Round, Fine Feed (Geared)

• Drilling Capacity: 40 mm (1.5 inches)
• Spindle Speed: Eight speeds
• Speed Range: 87 to 3600 RPM
• Spindle Nose: MT-4 (Morse Taper 4)
• Spindle Center to Column: 250 mm
• Spindle Travel: 150 mm
• Maximum Distance Spindle to Table: 930 mm
• Maximum Distance Spindle to Base: 1200 mm
• Working Surface of Base: 360 mm x 400 mm
• Working Surface of Table: 395 mm round
• Column Diameter: 74 mm
• Machine Base Dimensions: 550 mm x 380 mm
• Motor Power / RPM: 1.5 HP / 1440 RPM
• V-Belt Size: B-52
• Weight of Machine (Approx.): 155 kg
• Model Type: RTD 17 H (Regular Duty, Round)
• Feed Type: Fine feed model (geared)

• Model: HMP – 17 H (Regular Duty, Round)
• Drilling Capacity: 40 mm
• Spindle Speed: Eight-speed options
• Speed Range: 87 to 3600 RPM
• Spindle Nose: MT-4 (Morse Taper)
• Spindle Centre to Column: 250 mm
• Spindle Travel: 150 mm
• Maximum Distance from Spindle to Table: 930 mm
• Maximum Distance from Spindle to Base: 1200 mm

• Base Surface: 360 x 400 mm
• Table Surface: 395 mm (Round)
• Column Diameter: 74 mm

• Motor Power: 1.5 HP
• Motor Speed: 1440 RPM
• V-Belt Size: B-52

• Machine Base Dimensions: 550 x 380 mm
• Weight: 155 kg (approx.)
• Feed Type: Fine feed model (geared)

Model: RTD-18

• Drilling Capacity: 25 mm
• Spindle Speed: Eight speeds
• Speed Range: 87 to 3600 RPM
• Spindle Nose: MT-3 (Morse Taper 3)
• Spindle Centre to Column: 250 mm
• Spindle Travel: 150 mm
• Max Distance Spindle to Table: 930 mm
• Max Distance Spindle to Base: 1200 mm
• Working Surface of Base: 360 x 400 mm
• Working Surface of Table: 320 x 320 mm
• Column Diameter: 74 mm
• Machine Base Dimensions: 550 x 380 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-52
• Weight of Machine (Approx.): 160 kg
• Duty Type: Regular Duty (Square)
• Feed Type: Fine Feed (Geared)

• Drilling Capacity: 25 mm
• Spindle Speed: 8-speed variations
• Speed Range: 87 to 3600 RPM
• Spindle Nose: MT-3 (Morse Taper 3)
• Spindle Centre to Column: 250 mm
• Spindle Travel: 150 mm

• Max. Distance from Spindle to Table: 930 mm
• Max. Distance from Spindle to Base: 1200 mm
• Working Surface of Base: 360 mm x 400 mm
• Working Surface of Table: 320 mm x 320 mm
• Column Diameter: 74 mm
• Machine Base Dimensions: 550 mm x 380 mm

• Motor Power: 1.5 HP
• Motor RPM: 1440 RPM
• V-Belt Size: B-52

• Weight: Approx. 160 kg
• Model Type: RTD 18 - Regular Duty (Square)
• Fine Feed Model (Geared)

• Drilling Capacity: 40 mm
• Spindle Speed: Eight-speed (87 to 3600 RPM)
• Spindle Nose: MT-4
• Spindle Centre to Column: 250 mm
• Spindle Travel: 150 mm
• Max Distance Spindle to Table: 930 mm
• Max Distance Spindle to Base: 1200 mm
• Working Surface of Base: 360 x 400 mm
• Working Surface of Table: 320 x 320 mm
• Column Diameter: 74 mm
• Machine Base Dimensions: 550 x 380 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-52
• Weight: Approx. 160 kg
• Duty Type: Regular Duty (Square)
• Feed Type: Fine Feed (Geared)

Model: RTD-18 H
Type: Pillar Drilling Machine
Date: 01-01-2024

Drilling Capacity: 40 mm
Spindle Speed: 8 speeds
Speed Range: 87 to 3600 RPM
Spindle Nose: MT-4
Spindle Center to Column: 250 mm
Spindle Travel: 150 mm
Maximum Distance Spindle to Table: 930 mm
Maximum Distance Spindle to Base: 1200 mm
Working Surface of Base: 360 x 400 mm
Working Surface of Table: 320 x 320 mm
Column Diameter: 74 mm
Machine Base Dimensions: 550 x 380 mm
Motor: 1.5 HP / 1440 RPM
V-Belt Size: B-52
Weight of Machine (Approx.): 160 kg

Special Features:

• Regular Duty
• Fine Feed Model (Geared)

Specifications:

• Drilling Capacity: 25 mm
• Spindle Speed: Eight Speed Settings
• Speed Range: 120 to 2800 RPM
• Spindle Nose: MT-4
• Spindle Centre to Column: 250 mm
• Spindle Travel: 155 mm
• Max Distance Spindle to Table: 830 mm
• Max Distance Spindle to Base: 1050 mm
• Working Surface of Base: 360 x 400 mm
• Working Surface of Table: 330 x 330 mm
• Column Diameter: 87 mm
• Machine Base Dimensions: 560 x 400 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-52
• Approximate Weight: 200 kg
• RTD: 19 (Square)

• Maximum Drilling Diameter: 25 mm

• Speed Options: Eight speeds
• Speed Range: 120 to 2800 RPM
• Spindle Nose: MT-4 (Morse Taper 4)
• Spindle Travel: 155 mm

• Spindle Center to Column: 250 mm
• Maximum Distance Spindle to Table: 830 mm
• Maximum Distance Spindle to Base: 1050 mm

• Base Working Surface: 360 x 400 mm
• Table Working Surface: 330 x 330 mm

• Column Diameter: 87 mm
• Machine Base Dimensions: 560 x 400 mm

• Power: 1.5 HP
• RPM: 1440 RPM

• V-Belt Size: B-52

• Approximate Weight: 200 kg

• Fine Feed Mechanism: Geared
• RTD 19 – (Square): This could refer to a specific part or attachment for the machine, possibly for rigidity or additional support.

• Drilling Capacity: 25 mm
• Spindle Speed: 8 Speed Options
• Speed Range: 87 to 1850 RPM
• Spindle Nose: MT-4
• Spindle Centre to Column: 250 mm
• Spindle Travel: 250 mm
• Max Distance Spindle to Table: 830 mm
• Max Distance Spindle to Base: 1050 mm
• Base Working Surface: 360 x 400 mm
• Table Working Surface: 395 mm (Round)
• Column Diameter: 87 mm
• Machine Base Dimensions: 560 x 400 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-52
• Approximate Weight: 230 kg
• Feed Mechanism: Fine Feed (Geared)

Model: RTD-22

• Drilling Capacity: 40 mm (1.5”)
• Spindle Speed: Eight speeds
• Speed Range: 120 to 2800 RPM
• Spindle Nose: MT-4
• Spindle Centre to Column: 250 mm
• Spindle Travel: 155 mm
• Max Distance Spindle to Table: 830 mm
• Max Distance Spindle to Base: 1050 mm
• Working Surface of Base: 360 x 400 mm
• Working Surface of Table: 330 x 330 mm
• Column Diameter: 87 mm
• Machine Base Dimensions: 560 x 400 mm
• Motor: 1.5 HP, 1440 RPM
• V-Belt Size: B-52
• Weight of Machine: Approx. 200 kg
• Feed Mechanism: Fine feed (geared)

• Drilling Capacity: 40 mm
• Spindle Speed: Eight speeds (120 to 2800 RPM)
• Spindle Nose: MT-4
• Spindle Centre to Column: 250 mm
• Spindle Travel: 250 mm
• Max Distance (Spindle to Table): 830 mm
• Max Distance (Spindle to Base): 1050 mm
• Base Working Surface: 360 x 400 mm
• Table Working Surface: 330 x 330 mm
• Column Diameter: 87 mm
• Machine Base Dimensions: 560 x 400 mm
• Motor: 1.5 HP, 1440 RPM
• V-Belt Size: B-52
• Approximate Weight: 200 kg
• Features: Fine feed mechanism (geared)

• Drilling Capacity: 40 mm (1.5 inches)
• Spindle Speed: 8 speeds
• Speed Range: 120 to 2800 RPM
• Spindle Nose: MT-4 (Morse Taper No. 4)
• Spindle Centre to Column: 250 mm
• Spindle Travel: 250 mm
• Max Distance Spindle to Table: 830 mm
• Max Distance Spindle to Base: 1050 mm
• Working Surface of Base: 360 x 400 mm
• Working Surface of Table: 330 x 330 mm
• Column Diameter: 87 mm
• Machine Base: 560 x 400 mm
• Motor: 1.5 HP, 1440 RPM
• V-Belt Size: B-52
• Weight: Approx. 200 kg
• Feed Mechanism: Fine feed (geared)

• Drilling Capacity: 40 mm (1.5”)
• Spindle Speed: Eight speeds
• Speed Range: 87 to 1850 RPM
• Spindle Nose: MT-4
• Spindle Center to Column: 250 mm
• Spindle Travel: 250 mm
• Max Distance Spindle to Table: 830 mm
• Max Distance Spindle to Base: 1050 mm
• Working Surface of Base: 360 x 400 mm
• Working Surface of Table: 395 mm (Round)
• Column Diameter: 87 mm
• Machine Base Dimensions: 560 x 400 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-52
• Weight of Machine: Approximately 230 kg
• Type: Medium Duty (Round)
• Feed Mechanism: Fine feed (geared)

• Drilling Capacity: 40 mm (1.5 inches)
• Spindle Speed: Eight speeds (87 to 1850 RPM)
• Spindle Nose: MT-4
• Spindle Center to Column: 300 mm
• Spindle Travel: 310 mm
• Max Distance Spindle to Table: 850 mm
• Max Distance Spindle to Base: 1050 mm
• Working Surface of Base: 420 x 420 mm
• Working Surface of Table: 495 mm (round)
• Column Diameter: 100 mm
• Machine Base: 645 x 420 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-58
• Weight of Machine: Approx. 280 kg
• Duty Type: Medium duty (round)
• Feed Mechanism: Fine feed (geared)

RTD-23 C Pillar Drilling Machine:

• Drilling Capacity: 40 mm (1.5”)
• Spindle Speed: 8 speeds (120 to 2800 RPM)
• Spindle Nose: MT-4
• Spindle Centre to Column: 350 mm
• Spindle Travel: 155 mm
• Max Distance Spindle to Table: 830 mm
• Max Distance Spindle to Base: 1050 mm
• Base Working Surface: 420 x 420 mm
• Table Working Surface: 330 x 330 mm
• Column Diameter: 87 mm
• Machine Base Dimensions: 645 x 420 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-60
• Approx. Weight: 220 kg
• Feed Mechanism: Fine feed mechanism (geared)

• Model: RTD-23 C
• Drilling Capacity: 40 mm (1.5 inches)
• Spindle Speed: Eight speeds
• Speed Range: 120 to 2800 RPM
• Spindle Nose: MT-4 (Morse Taper #4)
• Spindle Center to Column: 350 mm
• Spindle Travel: 155 mm
• Maximum Distance Spindle to Table: 830 mm
• Maximum Distance Spindle to Base: 1050 mm
• Working Surface of Base: 420 x 420 mm
• Working Surface of Table: 330 x 330 mm
• Column Diameter: 87 mm
• Machine Base: 645 x 420 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-60
• Weight of Machine (Approx.): 220 kg
• Features: Square design, fine feed mechanism (geared)

• Drilling Capacity: 40 mm (1.5”)
• Spindle Speed: 8 speeds
• Speed Range: 87 to 1850 RPM
• Spindle Nose: MT-4
• Spindle Center to Column: 375 mm
• Spindle Travel: 310 mm
• Max Distance Spindle to Table: 850 mm
• Max Distance Spindle to Base: 1050 mm
• Working Surface of Base: 420 x 420 mm
• Working Surface of Table: 495 mm (round)
• Column Diameter: 100 mm
• Machine Base Dimensions: 645 x 420 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-65
• Weight of Machine: Approx. 340 kg
• Type: Heavy Duty (Round)
• Fine Feed Mechanism: Geared

Specifications:

• Drilling Capacity: 40 mm (1.5 inches)
• Spindle Speed: 8 speeds
• Speed Range: 100 to 2435 RPM
• Spindle Nose: MT-4
• Spindle Center to Column: 380 mm
• Spindle Travel: 250 mm
• Max Distance Spindle to Table: 850 mm
• Max Distance Spindle to Base: 1050 mm
• Working Surface of Base: 650 x 520 mm
• Working Surface of Table: 440 x 440 mm
• Column Diameter: 100 mm
• Machine Base Dimensions: 750 x 560 mm
• Motor: 1.5 HP / 1440 RPM
• V-Belt Size: B-72
• Weight of Machine (Approx.): 430 kg
• Type: Heavy Duty (Square)
• Fine Feed Mechanism: Geared

• Model: RTD-24
• Drilling Capacity: 40 mm (1.5 inches)
• Spindle Speed: Eight speeds
• Speed Range: 100 to 2435 RPM
• Spindle Nose: MT-4 (Morse Taper 4)
• Spindle Centre to Column: 380 mm
• Spindle Travel: 250 mm
• Maximum Distance Spindle to Table: 850 mm
• Maximum Distance Spindle to Base: 1050 mm
• Working Surface of Base: 650 x 520 mm
• Working Surface of Table: 440 x 440 mm
• Column Diameter: 130 mm
• Machine Base: 750 x 560 mm
• Motor: 1.5 HP, 1440 RPM
• V-Belt Size: B-72
• Weight of Machine (Approx.): 430 kg
• Features: Heavy-duty, square design, fine feed mechanism (geared)

This is a specification sheet for a 13 mm (1/2 inch) Pillar Drilling Machine, specifically the RTD-C3 model. Below is a breakdown of the key specifications:

1. Drilling Capacity: 13 mm
2. Spindle Speed: Four speeds
3. Speed Range: 650 to 2400 RPM
4. Spindle Nose: 6-J Taper
5. Spindle Centre to Column Distance: 100 mm
6. Spindle Travel: 72 mm
7. Maximum Distance (Spindle to Table): 370 mm
8. Maximum Distance (Spindle to Base): 450 mm
9. Working Surface of Base: 170 x 140 mm
10. Working Surface of Table: 160 x 160 mm
11. Column Diameter: 47 mm
12. Machine Base Size: 280 x 170 mm
13. Motor Specifications: 0.5 HP / 1440 RPM
14. V-Belt Size: FHP-2340
15. Machine Weight (Approx.): 22 kg
16. Chuck Type: RTD C3 (ECO)
17. Raising Mechanism: Rack and Pinion type

This is a detailed specification for a 13 mm Pillar Drilling Machine, Model RTD – C 3. Here’s a breakdown of its key features and capabilities:

1. Drilling Capacity: 13 mm (1/2”)
2. Spindle Speed: Four adjustable speeds
3. Speed Range: 650 to 2400 RPM
4. Spindle Nose: 6-J taper
5. Spindle Centre to Column: 100 mm
6. Spindle Travel: 72 mm
7. Max. Distance (Spindle to Table): 370 mm
8. Max. Distance (Spindle to Base): 450 mm
9. Working Surface (Base): 170 x 140 mm
10. Working Surface (Table): 160 x 160 mm
11. Column Diameter: 47 mm
12. Machine Base Dimensions: 280 x 170 mm
13. Motor Power: 0.5 HP, with a speed of 1440 RPM
14. V-Belt Size: FHP-2340
15. Machine Weight: Approx. 22 kg
16. Chuck Type: RTD C3 Chuck Type (Eco)
17. Rack and Pinion Type Mechanism for adjustable height and positioning.
